Modular UPS

STRATUS POWER

Modular Online Uninterruptable Power Supply

CENTIEL STRATUS - Modular High Power Online UPS

Hot-Swap Modules
Easily Scalable
3:3 Phase
Up to 3.75MW
Ideal for Datacenters

The CENTIEL StratusPower Series is a state-of-the-art modular three-phase UPS designed for the highest level of power availability in critical data center and infrastructure environments. Built on the Distributed Active Redundant Architecture (DARA™), it eliminates single points of failure to provide "9 nines" (99.9999999%) availability and fully fault-tolerant operation. The system achieves an industry-leading VFI efficiency of 97.6%, significantly reducing energy waste and supporting net-zero sustainability goals through a highly compact footprint. Its exceptional power density allows for up to 1,500 kW in a single cabinet, with parallel scalability reaching 3.75 MW for large-scale operations.

Request a quote Datasheet PDF, 3.0 MB

Three Centiel StratusPower modular UPS cabinets side by side with perforated doors, stacked hot-swap power modules and a colour touchscreen on the lead cabinet

Inverter efficiency: 97,6%
Power availability: 99.9999999%
Max. nom. power per frame: 1500kVA = kW
UPS design life: 30+years

Product Overview

StratusPower is an innovative uninterruptible power supply (UPS), specifically designed to meet the rigorous demands of today’s IT infrastructure.

Designed and manufactured in Switzerland, StratusPower’s superior topology, referred to as DARA, ensures full availability with no single point of failure, providing data center operators with complete peace of mind. Furthermore, installation of StratusPower is straightforward and maintenance is simple and non-intrusive.

Technical Highlights

High 97.7% VFI efficiency with reliablable semiconductor technology
1 MW/m2 - Space saving power foorprint
99.9999999 % availability and no single point of failure
Fully redundant with DARA - fault-tolerant architecture
Fully connected with multi-protocol and a full range of communication channels available
From 10 kW – 3.75 MW In cabinets from 10 kW to 1.5 MW
Non-intrusive maintenance 15+ years caps and smart fans
Smart energy peak-shaving, self-test

99.9999999 % availability

No single point of failure
Fully redundant

DARA - fault-tolerant architecture
Fully connected

multi-protocol and a full range of communication channels available
From 10 kW – 3.75 MW

In cabinets from 10 kW to 1.5 MW
Non-intrusive maintenance

15+ years caps and smart fans
Smart energy

peak-shaving, self-test

Key features

DC Flex technology

Our unique DCFlex© technology offers unparalleled flexibility when it comes to battery storage installation and configuration, as well as preparing the infrastructure to manage both current and future energy sources. Our UPS solution is compatible with various battery storage devices, allowing you to reuse the DC supply or to choose the option that best suits your needs and budget. The StratusPower battery charging current capability is 500 percent higher than our closest competitors, meaning faster charging times and more efficient use of your batteries.

Robust and reliable semiconductor technology

The StratusPower incorporates proprietary technology for inverter physical isolation in the event of an IGBT failure, ensuring maximum uptime for your critical infrastructure. The triple-mode parallel bus provides an extra layer of redundancy, eliminating any single point of failure in communication between frames and modules. At Centiel, we take reliability very seriously. That’s why we designed our technology with extra-safe power of 24%, ensuring a higher level of reliability and redundancy. With continuous operating capacity, each module can operate at 75 kW even under overload conditions. The 750 kW StratusPower UPS has the ability to operate in online mode, supporting loads up to 900 kW.

Predictive and remote health monitoring

With its computing capabilities and more than 100 measurement points, StratusPower does the work for you, ensuring that maintenance is performed promptly and accurately.This not only saves time and effort but also improves your system’s overall reliability and safety. Bluetooth connectivity allows technicians for easy, non-intrusive monitoring via mobile devices, with the Centiel app providing real-time status updates and alerts. StratusPower provides advanced cybersecurity features in compliance with IEC-4-62443-2, making certain that your critical data and systems are protected from cyber threats.

Exceeding performance expectations

With a THDi of less than 1 percent, StratusPower provides excellent performance that exceeds regulatory requirements. The UPS is able to handle 124% of continuous overload and 125% overload for 2 minutes, ensuring uninterrupted power delivery during times of peak demand. A short circuit capability above 3xIn safeguards your equipment and system integrity despite electrical faults.

Advanced computing power

Multi-core, Trigonometric math unit, Control law accelerator, Parallel processing, IEEE 754 double-precision math

External ambient monitoring

Temperature, Humidity, Hydrogen, Water leak

Technical specifications

The figures below are reproduced from Centiel's StratusPower technical datasheet, which covers eight cabinet configurations built from the SM10/SM20/SM25/SM30 and SM50/SM62 module families.

STRATUS POWER technical specifications, compared across 8 models.
Model	CAB-SP060-I080-A1 CAB-SP060-I240-A0	CAB-SP120-E-A1 CAB-SP120-I320-B0	CAB-SP180-E-A0	CAB-SP300-E-B0-S2	CAB-SP375B-E-K CAB-SP375T-E-K	CAB-SP750B-E-2K CAB-SP750T-E-2K	CAB-SP1125B-E-3K CAB-SP1125T-E-3K	CAB-SP1500B-E-4K CAB-SP1500T-E-4K
General Data
Module type	SM10/SM20/SM25/SM30				SM50 / SM62
Nom. power per module [kVA = kW]	10 / 20 / 25 / 30				50 / 62.5
Cont. overload per module [kVA = kW]	12 / 24 / 30 / 36				60/75
Nom. power per frame [kVA = kW]	60	120	180	300	375	750	1125	1500
Cont. overload per frame [kVA = kW]	74	149	223	372	450	900	1350	1800
Number of modules per frame	1-2	1-4	1-6	1-10	1-6	1-12	1-18	1-24
Max. power per system [kVA = kW]	3600	7200	10800	18000	3750
Topology / technology	Online double conversion / DARA (Distributed Active Redundant Architecture)
Input — Rectifier
Input wiring	3 Ph + N + PE
Rated voltage	380/400/415Vac
Voltage range	For loads <100% (−25%, +20%), <80% (−32.5%, +20%), <60% (−35%, +20%)
Input frequency	30-70 Hz
Total Harmonic Distortion	THDi<0.8% for linear load, THDi<3% for nonlinear load
Input power factor	0,99
Input — Bypass
Input wiring	3 Ph + N + PE
Rated voltage	±30…±10% (Voltage) (According to VFI-SS-111)
Input frequency	50/60 ±2/4% (selectable)
Input — Battery
Rated voltage	280 - 480 Vdc (the number of batteries can be selected )				240 - 600 Vdc (the number of batteries can be selected )
Internal batteries (7/9Ah)	I080: 80 I240: 240	E: External I320: 320	E: External
Type	Lead-Acid / NiCad / Lithium / Zink / Salt / others...
Blocks[LA]	20-50
Charger (Amps per module)	—				50
Output — Inverter
Output wiring	3Ph+N+PE
Voltage	380/400/415 Vac				380/400/415 Vac±1%
Frequency	Tracking the bypass input (Online Mode); 50 / 60 Hz ± 0.05% (Battery Mode)
Output power factor	1
Efficiency	97,6%
Overload capacity	Inverter: 124% continuous, 125% for 10min, 150% for 60 sec				Inverter: 124% continuous, 125% for 15min, 150% for 120 sec
Output — Bypass
Efficiency	99,4%
Environment
Operating temperature	0-40°C (No power derating)
Storage temperature	-40-70°C
Relative humidity	0%-95% (No condensing)
Maximum operating altitude	1000 m. above 1000 m, derating 1% for each additional 100 m
Others
Dimensions (H x W x D) [mm]	1315 x 510 x 815 1980 x 510 x 815	1315 x 510 x 815 1980 x 730 x 815	1980 x 510 x 815	1980 x 730 x 815	1982 x 656 x 900	1982 x 1312 x 900	1982 x 1968 x 900	1982 x 2624 x 900
Certifications	EN/IEC 62040-1\| EN/IEC 62040-2 \| EN/IEC 62040-3 \| CE \| UKCA \| EAC \| RoHS
Communications	RS485, USB, Dry contacts, Ethernet, Bluetooth

+ The information in this document is subject to change without notice and should not be construed as a commitment by Centiel S.A.

Where the STRATUS POWER is used

Frequently asked questions

Answers taken from the STRATUS POWER datasheet.

What power range does the Centiel StratusPower modular UPS cover?

StratusPower is a modular three-phase UPS covering 10 kW to 3.75 MW. It uses SM10/SM20/SM25/SM30 modules rated 10/20/25/30 kW and SM50/SM62 modules rated 50/62.5 kW, with nominal power per frame from 60 kVA = kW up to 1500 kVA = kW and a maximum of 3750 kVA = kW per system.

What is DARA architecture in the Centiel StratusPower UPS?

DARA is Centiel's Distributed Active Redundant Architecture, the online double conversion topology used by StratusPower. Each UPS module is independent, redundant and interconnected, and is a complete UPS system in its own right with three independent power converters, a static bypass and all the hardware devices needed to safely isolate a fault without impacting the load. Its Distributed Decision Making technology (DDM) eliminates the single point of failure typically associated with master-slave technology.

How efficient is the StratusPower UPS in VFI double conversion mode?

The inverter efficiency is 97,6% and the bypass efficiency is 99,4%. Input distortion is THDi<0.8% for linear load and THDi<3% for nonlinear load, with an input power factor of 0,99 and an output power factor of 1.

What are the operating temperature and altitude limits of the Centiel StratusPower?

Operating temperature is 0-40°C with no power derating, storage temperature is -40-70°C and relative humidity is 0%-95% (No condensing). Maximum operating altitude is 1000 m; above 1000 m the unit derates 1% for each additional 100 m.

What communication interfaces does the StratusPower modular UPS provide?

The cabinets provide RS485, USB, Dry contacts, Ethernet and Bluetooth. The Universal Rack UPS connectivity board adds 5x dry output, 5x dry input, RS232, RS485, Bluetooth, Ethernet and a slot for SNMP, and Bluetooth allows technicians non-intrusive monitoring via mobile devices with the Centiel app.

Which standards and certifications does the Centiel StratusPower comply with?

StratusPower carries EN/IEC 62040-1, EN/IEC 62040-2, EN/IEC 62040-3, CE, UKCA, EAC and RoHS. Its cybersecurity features comply with IEC-4-62443-2, and the bypass rated voltage follows VFI-SS-111.
